5gm to 250gm Filling Linear Medicine Tube Filling Sealing Machine 80-120 Tube Per Minute
5gm to 250gm Filling Linear Medicine Tube Filling Sealing Machine 80-120 Tube Per Minute is having applications for metal, plastic, polyfoil and laminate tubes with cassette infeed system. This machine is designed and constructed according to the highest technology standards to guarantee the maximum productivity and quality. Equipment complies according to cGMP standards and therefore suitable for sterile rooms and laminar flows. Easy changeover without tools in very less time. A mechanical lifting mechanism or run by a servo motor (upon request) controls the lifting and descending of the tube according to the fill product characteristics. Excellent access for cleaning and maintenance.
We offer a wide range of Automatic Linear Tube Filling Machines for the Cosmetic, Food, Chemical and Pharmaceutical Industries as per our standard models or according to customer’s specific requirements. Our machine designed to fill Single tube large and small, side by side, dual product. Our machine sealing types include: Aluminium crimping and folding, hot air sealing for plastic and laminates. Our machines can be customized to fit your production needs.
What is tube filling and sealing machine?
Tube filling and sealing machine is the semi automatic or full automatic system for unit dose filling and closing of the squeezable plastic, laminate, or metal aluminum tube.
How does a tube filler work?
On full automatic tube filler, the empty tubes will be fed onto the machine from tube bin automatically and then inserted into the tube base. The liquid and semi liquid product will be transferred into the tank by a pump and fill into the empty tube. Then the tube will be closed by sealing or folding ( for metal tubes). The batch No embossing can be added by stainless steel letter embossing.
Seal Style:
A-type Heat sealing machine for composite/ plastic tube :
Using hot air gun internal heating and water cooling machine, perfect completion of plastic hose sealing work, sealing strong and beautiful without deformation .
B-type Folding sealing machine for matel aluminum tube :
Changing different parts and do some adjustment can achieve 3 side folding ,5 side folding and other folding ways.
Application for tube filling sealing machine
The filling and packing object for tube fill sealing machine is liquid and semi-liquid, it could be widely applied in various sectors as following chart:
Sector | Classification |
Personal Care & Cosmetic | Bleach cream |
Hair color/Hair gel | |
Lotion | |
Essence/Face serum | |
Body/Hand Cream | |
Facial cleanser | |
Shampoo (Hair/Body gel) | |
Washing soap | |
Toothpaste | |
Chemical | Wall painting gel/cream |
Adhesive | |
Glue | |
Pigment | |
Food | Ketchup |
Peanut /fruit Jam | |
Tomato paste | |
Mustard |
Main Features
1.The drive part is fully closed under the operation platform, safe and reliable without pollution;
2.Stainless steel operation panel with touch screen
3.Two hanging types of tube bin: inclined or direct
4.Photo electrical eye mark tracking for precision location
5.No tube, no filling
6.Inner side Leister hot air sealing while the external part is equipped with cooling device to reduce temperature
7.Stainless steel letter embossing for EXP,batch No.
8.Various of tube sealing are available, such as curved, slot, rounded corners or customized profiles
9.Alarm for any fault and stop for overload;
10.Auto counting or machine stop at certain quantify
Main Technical Parameters
