China, Japan, South Korea, North Korea, Vietnam, Thailand, Indonesia, Malaysia, the Philippines, Myanmar and Ryukyu all celebrate this traditional festival on the 15th day of the eighth lunar month.This is also the result of the long history of Chinese culture.
Main application:
The blister packing machine is special for Pharmaceutical/ Food / Cosmetic/ Chemical etc industrial usage. It has the function of packaging,detecting and rejection. It adopted PLC control system, touch screen interface, frequency converter system, which make the machine automatic running more stable and enhance the machine life time. The machine can use ALU PVC, ALU ALU, PVC PAPER material for blister packaging. It meet GMP standard.
Operating principle:
1.The travel scope is adjustable, and the mold is located in the groove for easy mold changing.
Working Process:
Colorful Printed Sheet (PET/PVC/HIPS) Roll Unwinding→Heating→Position Forming→Liquid Jelly→Printed Aluminum Foil/Printed Film Position Hot Sealing→Batch No. Impress(optional)→Servo Traction→Date Inkjet Printing (Optional)→Cutting→Products conveying out →Connection to other line equipment, such as cartoning machines.
Main Technical Parameters
| Model | DPP-260 | DPP-350 | DPP-420S | DPP-420F |
| Application | Moon cake,solid,liquid,etc | Moon cake,solid,liquid,etc | capsule, tablet, honey pill, candy, liquid, syringe | surprise egg / toy egg/Fruit-type fudge |
| Packing speed | 10-25 times / min | 12-28 times / min | 6-35 times / min | 10-25 times / min |
| Max Forming | 260×180×26mm or customized | 350×180×32mm or customized | 400×180×26mm or customized | 390×180×26mm or customized |
| Stroke | 40-140mm | 100-240 | 40-180mm | 40-180mm |
| Main/Total Power | 8.5KW | 24KW | 2.2KW / 9.7kw | 2.2KW / 22kw |
| Power Supply | 380V/220V 50Hz | 380V/220V 50Hz | 380V/220V 50Hz | 380V/220V 50Hz |
| Packing Film | PVC Sheet 0.15-0.5×260mm | PP 1.1mm*350mm | PVC Sheet 0.15-0.5×420mm | PVC/PET Sheet 0.15-0.5×420mm |
| PTP Aluminum Foil 0.02-0.035×260m | PTP Aluminum Foil/PP/PE 0.1*350mm | PTP Aluminum Foil 0.02-0.035×420m | Laminated sealing Foil 0.05-0.1×420mm | |
| Dialysis Paper50-100g×260mm | Dialysis Paper50-100g×350mm | Dialysis Paper50-100g×420mm | ||
| Machine Weight | 1400KG | 3200KG | 2000kgs | 2500kgs |
| Machine Size | 3250*710*1700mm | 5250*1110*190mm | 4300×820×1600(L*W*H) | 6000×950×2000(L*W*H) |
