This is a toy factory in Indonesia, and the owner is Chinese.So there are a lot of Chinese people working here.
Basically, if you only speak Chinese, you can also communicate well.
Over the years, this factory has purchased all the packaging equipment from our company. This time, we need to serve a new production line, mainly carton packaging machine and paper-plastic blister card packaging machine.
so our technicians follow the equipment to the factory for technical support.
Nowadays, due to the restrictions of trade barriers in Europe and the United States, more and more small industrial production lines have to be transferred from China to Southeast Asian countries, and our equipment has also moved.Therefore, we have visited almost all Southeast Asian countries.
The machine is a very mature paper-plastic blister packaging machinery, very stable, affordable, popular with users around the world.
The toys packing speed of the machine is about 3000-4000 PCs/hour.
After-sales service: step-by-step operation teaching video, 7 * 24 online technical support, overseas local engineer on-site service (appointment required)
What is blister card packaging machine?
What is blister card packing machine and how do paper plastic blister packaging machines work?
Blister packaging machine is to heat the forming sheet, such as PVC/PET/PS in the mould to form the blister tray, fill the product into the tray from the auto pickup feeder, and then seal with sealing paper card.
Application of blister card packing machine
such as Toys,daily commodity ( razor, rubber,nipple,sticky hook),small hardware (battery, electronics, glue), stationery (pencil, eraser, correction fluid, solid glue) and so on.
Working Principle
The production process is PVC heating---Blister card forming---servo motor traction---blister card cutting---scrap collection---blister card grab to the rotary plate by manipulator--manual place the product--- paper card lay down ----blister and paper card sealing----product output
Machine Detail
*can design feeder according to your product shape
| Mode | GAC-380 | GAC-400 | GAC-330 | GAC-600 | GAC-800 | GAC-400H |
| Production speed | 15-20 cycles/min | 15-20 cycles/min | 8-14 cycles/min | 15-18 cycles/min | 10-15 cycles/min | 15-20 cycles/min |
| Stroke range | 30-200mm | 30-220mm | 30-300mm | 30-260mm | 30-200mm | 30-200mm |
| Max forming area(mm) | 370x170/370x200 | 370x170/370x230 | 315*250 | 550x170/550x230 | 180*400 | 180*350 |
| Max standard forming depth | 38/50mm | 38/50mm | 25/40mm | 38/50mm | 38/50mm | 38/50mm |
| Forming heating power | 3.5kw(*2) | 3.5kw(*2) | 3kw(*2) | 3.5kw(*2) | 3.5kw(*2) | 3.5kw(*2) |
| Heat sealing power | 4.5kw | 4.5kw | 3.5kw | 4.5kw | 3kw | / |
| Total power | 13.5kw | 13.5kw | 13kw | 13kw | 12kw | 15kw |
| Air consumption | consumption ≥0.5 m³/min | |||||
| Air Pressure | 0.5-0.8mpa | |||||
| Packing material （PVC/PET) | thickness0.15-0.5mm | |||||
| Max paper dimension | 170x400/220x350 | 400x250/170x500 | 320x255 | 600x250/600x300 | 220x450 | 200x400 |
| Total Weight | 2500kg | 2500kg | 3500kg | 2500kg | 1800kg | 2500kg |
| Machine dimension(L*W*H) | 4600*1550*1850mm | 4600*1550*1850mm | 6200*800*1880mm | 6200*800*1880mm | 2870*1950*1900mm | 5100*4190*1880mm |
More machine detail，Please contact me.
MIGRAND Machinery
Mobile/Wechat/Whatsapp: 0086-13787413551
Email: sales@grand-packing.com
